Rear Wiper Module Grommet

REMOVAL




1. Remove rear wiper module.




2. Remove the grommet by pinching the grommet and pulling outward to remove it from the rear glass.

INSTALLATION




1. Carefully insert the grommet into the rear window assembly. Make sure the grommet is seated to the window from both the inside and outside of the window.




2. Install the rear wiper module.
