Data Communication Component Views

WARNING: This page is about a different car, the 2007 Saturn Outlook. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Below Drivers Side I/P

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Audio Amplifier (UQA/UQG/UQS)
2	Body Control Module (BCM)
3	Brake Pedal Position Sensor
4	Accelerator Pedal Position (APP) Sensor
5	G301

Fig 2: Locating Data Link Connector

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Data Link Connector (DLC)
2	Pedal Assembly
3	Floor Panel

Fig 3: Locating GMLAN Resistor

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Rear Suspension Frame
2	GMLAN Resistor
