Electronic Traction Control Switch Replacement

Fig 1: Electronic Traction Control Switch
GM1771901Courtesy of GENERAL MOTORS CORP.
Electronic Traction Control Switch Replacement

Callout Component Name
1 Instrument Panel Lower Trim Plate.
Refer to Instrument Panel Lower Trim Plate Replacement .
2 Traction Control Switch
Tip:  Squeeze the tabs in order to release the switch from the trim plate.
