System Specifications
Timing Chain TensionerNo. 1 chain tensioner x Timing chain tensioner sub-assembly 9.0 N*m (92 kgf*cm, 80 in.*lbf)
Crankshaft Pulley
Torque 180 N*m (1,835 kgf*cm, 133 ft.*lbf)
Timing Cover
Install the timing chain cover with the 14 bolts and 2 nuts.
Torque:
for bolt A 9.0 N*m (92 kgf*cm, 80 in.*lbf)
for bolt B 25 N*m (255 kgf*cm, 18 ft.*lbf)
for bolt C 55 N*m (561 kgf*cm, 41 ft.*lbf)
for nut 11 N*m (112 kgf*cm, 8 ft.*lbf)
