Ignition Control Module: Testing and Inspection
IGNITION CONTROL SYSTEM1 Of 20:
2 Of 20:
3 Of 20:
4 Of 20:
5 Of 20:
6 Of 20:
7 Of 20:
8 Of 20:
9 Of 20:
10 Of 20:
11 Of 20:
12 Of 20:
13 Of 20:
14 Of 20:
15 Of 20:
16 Of 20:
17 Of 20:
18 Of 20:
19 Of 20:
20 Of 20:
CAUTION: After repair or replacement of faulty parts, conduct CLEAR MEMORY and INSPECTION MODES.
WIRING DIAGRAM
