Section 9 (Lubrication System (3.0L)): General Description: Component
WARNING: This page is about a different variant/trim than selected.
Tightening torque: N.m (kgf-m, ft-lb)
- T1:
6.4 (0.65, 4.7)
- T2:
7.8 (0.80, 5.8)
- T3:
18 (1.8, 13)
- T4:
34 (3.5, 25)
- T5:
37 (3.8, 27)
- T6:
44 (4.5, 33)
- T7:
90 (9.2, 67)
