Section 99 (Clutch System): Flywheel: Inspection

WARNING: This page is about a different car, the 2003 Subaru Impreza. However, it is still accessible from the selected car via links, so may be relevant.

CAUTION: Since this bearing is grease sealed and is of a non-lubrication type, do not wash with gasoline or any solvent.

Damage of facing and ring gear:
If defective, replace the flywheel.

Fig 1: Replacing Flywheel
Courtesy of SUBARU OF AMERICA, INC.
Smoothness of rotation:
Rotate the ball bearing applying pressure in thrust direction.
If noise or excessive play is noted, replace the flywheel.
