Security Control Module: Removal

WARNING: This page is about a different car, the 2003 Subaru Forester. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the ground cable from battery.
Remove the glove box. Refer to REMOVAL , Glove Box.
Disconnect the connector from the security control module.
Remove nuts (A) and cruise control module (B).

Fig 1: Removing Nuts & Cruise Control Module
Courtesy of SUBARU OF AMERICA, INC.
Remove the security control module (C).
