Check Manual Mode Switch

CHECK MANUAL MODE SWITCH

DIAGNOSIS:

Input signal circuit of manual mode switch is open or shorted.

TROUBLE SYMPTOM:

Does not shift on manual mode.

WIRING DIAGRAM:
