Example Of DTC Data Not Received
WARNING:
This page is about a different car, the 2021 Subaru Ascent. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of SUBARU OF AMERICA, INC.
No. 17 DCM (BODY CAN) vicinity
Courtesy of SUBARU OF AMERICA, INC.
No. 30 steering angle sensor vicinity
Courtesy of SUBARU OF AMERICA, INC.
