Automatic Stop
- Connect a jumper between battery voltage and Yellow/Blue wire on Sidekick, Yellow/Black wire on Swift or Yellow wire on Samurai. Connect a second jumper wire between negative battery terminal and wiper motor ground.
- Use a paper clip jumper to short Orange and Blue/Green wire terminals. See Fig 1
. Motor should stop at park position. Remove paper clip and short same wires again. Motor should stop at same point. If motor does not stop at same point, replace motor.
Courtesy of SUZUKI OF AMERICA CORP.
