Subframe Assembly - Rear - Remove And Install: Notes
WARNING: This page is about a different car, the 2024 Tesla Model X, 2023 Tesla Model X, 2022 Tesla Model X, and 2021 Tesla Model X. However, it is still accessible from the selected car via links, so may be relevant.
Last modified: 10/11/2023 01:59:15
NOTE:
See Personal Protection
to make sure proper PPE is worn when performing the below procedure.
Revision History:
- 2023-11-01: Added steps for dummy plug on HV battery RH HV header.
- 2023-06-22: Updated suspension ride height check.
WARNING:
This procedure is a DRAFT, although it has been validated. Warnings and Cautions might be missing. Follow safety requirements and use extreme caution when working on or near high voltage systems and components. Provide corrections and feedback to ServiceDevelopment@teslamotors.com.
