Torque Specifications

TORQUE SPECIFICATIONS - ANKLE CATCHER (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolts that attach the front bumper beam to the ankle catcher	16 N.m (11.8 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench 3 in extension	Reuse
Bolts that attach the front end carrier to the LH subframe crash cans	16 N.m (11.8 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench 6 in extension	Reuse
Bolt that attaches the front end carrier to the LH side of the ankle catcher	7 N.m (5.2 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench 3 in extension	Reuse

TORQUE SPECIFICATIONS - BRACKET, FASCIA CENTER TO FENDER, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolt that attaches the headlamp to the lower front headlamp	5.9 N.m (4.4 ft-lbs)	Torx T30 socket Flex head ratchet/flex head torque wrench 2 in extension	Reuse
Bolt that attaches the LH front fascia center bracket to the vehicle	5 N.m (3.7 ft-lbs)	Torx T25 socket Flex head ratchet/flex head torque wrench	Replace with black bolt (1551442-00-A)

TORQUE SPECIFICATIONS - BRACKET, TAILLIGHT, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts that attach the LH taillight bracket to the vehicle	4 N.m (2.9 ft-lbs)	10 mm socket 4 in extension	Reuse

TORQUE SPECIFICATIONS - BRACKET - FRONT END MODULE (FEM) - LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolts that attach the LH front end module bracket to the vehicle	35 N.m (25.8 lbs-ft)	13 mm socket Ratchet/torque wrench	Reuse
Bolt that attaches the LH front fender bracket to the front fender assembly	9.8 N.m (7.2 lbs-ft)	10 mm deep socket 4 in extension Ratchet/torque wrench	Reuse
Bolt that attach the LH front end module braket to the front end carrier	16 N.m (11.8 lbs-ft)	13 mm socket 6 in extension Flex head ratchet/flex head torque wrench	Reuse

TORQUE SPECIFICATIONS - BRACKET, FASCIA SIDE TO FENDER, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolts that attach the top of the front fascia to the vehicle	4 N.m (2.9 ft-lbs)	10 mm socket 2 in extension	Reuse
Bolt that attaches the LH corner of the front fascia to the fender	4 N.m (2.9 ft-lbs)	10 mm socket	Reuse
Bolts that attach the LH fascia side to fender bracket	4 N.m (2.9 ft-lbs)	10 mm socket 6 in extension	Reuse

TORQUE SPECIFICATIONS - CARRIER, FRONT END (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolts that attach LH and RH lower grille FEM brackets to the front end carrier	8 N.m (5.9 ft-lbs)	10 mm hex Flex head ratchet/flex head torque wrench 6 in extension	Reuse
Bolts that attach the front radar bracket to the front end carrier	8 N.m (5.9 ft-lbs)	10 mm socket Flex head ratchet/flex head torque wrench 6 in extension locking	Reuse
Bolts that attach the upper leg support to the front end carrier	8 N.m (5.9 ft-lbs)	10 mm socket Flex head ratchet/flex head torque wrench 4 in extension	Reuse
Bolts that attach the actuator to the front end carrier	8 N.m (5.9 ft-lbs)	10 mm socket Flex head ratchet/flex head torque wrench 4 in extension	Reuse
Bolts that attach the hood latch assembly to the front end carrier	8 N.m (5.9 ft-lbs)	10 mm socket Flex head ratchet/flex head torque wrench 4 in extension	Reuse
Bolt on top of the front end carrier	16 N.m (11.8 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench 6 in extension	Reuse
Bolts that attach the front bumper with the energy absorbers to the LH and RH crush cans	75 N.m (55.3 ft-lbs)	15 mm socket Flex head ratchet/flex head torque wrench 3 in extension	Replace
Bolt that attaches the front bumper beam to the LH side of the ankle catcher	16 N.m (11.8 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench 3 in extension	Reuse
Bolt that attaches the front end carrier to the LH side of the ankle catcher	7 N.m (5.2 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench 3 in extension	Reuse
Bolts that attach the front end carrier to the LH subframe crash cans	16 N.m (11.8 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench 6 in extension	Reuse
Bolts that attach the LH and RH of the cooling fan module to the vehicle	10 N.m (7.4 ft-lbs)	8 mm socket Flex head ratchet/flex head torque wrench 4 in extension	Reuse
Bolt that attaches the LH corner of the front fascia to the fender	4 N.m (2.9 ft-lbs)	10 mm socket 1/4 in std ratchet Wurth 1/4 in hexagon 1 N.m - 5 N.m torque wrench (installation only) 1/4 in hex to 1/4 in square 2 in adapter	Reuse
Bolts that attach the top of the front fascia to the vehicle	4 N.m (2.9 ft-lbs)	10 mm socket 1/4 in std ratchet 2 in extension Wurth 1/4 in hexagon 1 N.m - 5 N.m torque wrench (installation only) 1/4 in hex to 1/4 in square 2 in adapter	Reuse
Bolts that attach the underhood storage unit reinforcement bracket to the cooling fan	48 N.m (35.4 ft-lbs)	E14 socket Flex head ratchet/flex head torque wrench 3 in extension	Reuse

TORQUE SPECIFICATIONS - CHECK STRAP, DOOR, FRONT, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolt that attaches the check strap to the A-pillar	24 N.m (17.7 ft-lbs)	Torx T40 socket Flex head ratchet/flex head torque wrench	Reuse
Nuts that attach the check strap to the door	10 N.m (7.4 ft-lbs)	10 mm socket Flex head ratchet/flex head torque wrench	Reuse

TORQUE SPECIFICATIONS - CRUSH CAN, FRONT SUBFRAME, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolt that attaches the LH/RH side of the ankle catcher to the front bumper beam	16 N.m (11.8 ft-lbs)	13 mm socket 3 in extension Flex head ratchet/flex head torque wrench	Reuse
Bolt that attaches the LH/RH front subframe crush cans to the front end carrier	16 N.m (11.8 ft-lbs)	13 mm socket 6 in extension Flex head ratchet/flex head torque wrench	Reuse
Bolt that attaches the LH/RH side of the ankle catcher to the front end carrier	7 N.m (5.2 ft-lbs)	13 mm socket 3 in extension Flex head ratchet/flex head torque wrench	Reuse
Bolt that attaches the LH/RH front subframe crush cans to the front subframe	53 N.m (39.1 ft-lbs)	15 mm socket 3 in extension Flex head ratchet/flex head torque wrench	Reuse

TORQUE SPECIFICATIONS - DOOR, FRONT, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Nuts that attach the hinges to the LH front door	49 N.m (36.1 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench	Reuse
Bolts that attach the hinges to the LH front door	24 N.m (17.7 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench	Reuse

TORQUE SPECIFICATIONS - DOOR, REAR, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolt that attaches the LH rear door check strap to the body	24 N.m (17.7 ft-lbs)	Torx T40 socket Flex head ratchet/flex head torque wrench	Reuse
Nuts that attach the LH rear door check strap to the door	10 N.m (7.4 ft-lbs)	10 mm deep socket	Reuse
Nuts that attach the LH rear door hinges to the door	49 N.m (36.1 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench	Reuse
Bolts that attach the rear LH door to the upper and lower hinges	49 N.m (36.1 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench	Reuse

TORQUE SPECIFICATIONS - FASCIA, FRONT (REMOVE AND INSTALL)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts that attach the top of the front fascia to the vehicle	4 N.m (2.9 ft-lbs)	10 mm socket 1/4 in std ratchet 2 in extension Wurth 1/4 in hexagon 1 N.m - 5 N.m torque wrench (installation only) 1/4 in hex to 1/4 in square 2 in adapter	Reuse
Bolt that attaches the LH corner of the front fascia to the fender	4 N.m (2.9 ft-lbs)	10 mm socket 1/4 in std ratchet Wurth 1/4 in hexagon 1 N.m - 5 N.m torque wrench (installation only) 1/4 in hex to 1/4 in square 2 in adapter

TORQUE SPECIFICATIONS - FASCIA, FRONT (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Screws that attach the RH front turn signal/foglight to the front fascia	2.8 N.m (2.1 ft-lbs)	Torx T25 socket 4 in extension	Reuse
Screws that attach the front fascia grille to the front fascia	3 N.m (2.2 ft-lbs)	Torx T25 socket 4 in extension	Reuse
Nuts that attach the front fascia valance to the front fascia	3 N.m (2.2 ft-lbs)	10 mm socket 2 in extension	Reuse

TORQUE SPECIFICATIONS - FASCIA, REAR (REMOVE AND INSTALL)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolt that attaches the corner of the rear fascia to the body	4 N.m (2.9 ft-lbs)	10 mm hex	Reuse
Bolts that attach the rear diffuser to the body	4 N.m (2.9 ft-lbs)	10 mm socket 2 in extension	Reuse
Bolt that attaches the side of the rear fascia to the body	4 N.m (2.9 ft-lbs)	8 mm hex 4 in extension	Reuse

TORQUE SPECIFICATIONS - FENDER ASSEMBLY, FRONT, LH (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolts that attach the top of the front fascia to the vehicle	4 N.m (2.9 ft-lbs)	10 mm socket 1/4 in std ratchet 2 in extension Wurth 1/4 in hexagon 1 N.m - 5 N.m torque wrench (installation only) 1/4 in hex to 1/4 in square 2 in adapter	Reuse
Bolt that attaches the LH front wheel liner to the HV battery	5 N.m (3.7 ft-lbs)	10 mm socket 4 in extension	Reuse
Bolt that attaches the LH corner of the front fascia to the fender	4 N.m (2.9 ft-lbs)	10 mm socket 1/4 in std ratchet Wurth 1/4 in hexagon 1 N.m - 5 N.m torque wrench (installation only) 1/4 in hex to 1/4 in square 2 in adapter	Reuse Replace
Bolt that attaches the RH corner of the front fascia to the fender	4 N.m (2.9 ft-lbs)	10 mm socket 1/4 in std ratchet Wurth 1/4 in hexagon 1 N.m - 5 N.m torque wrench (installation only) 1/4 in hex to 1/4 in square 2 in adapter	Reuse
Bolts that attach the upper LH front fender bracket to the body	9.8 N.m (7.2 ft-lbs)	10 mm deep socket 4 in extension	Reuse
Bolt that attaches the LH front fender bracket to the body	9.8 N.m (7.2 ft-lbs)	10 mm deep socket 4 in extension	Reuse
Bolt that attaches the rear LH front fender bracket to the body	9.8 N.m (7.2 ft-lbs)	10 mm deep socket 4 in extension	Reuse
Nuts that attach the lower LH front fender bracket to the body	9.8 N.m (7.2 ft-lbs)	10 mm deep socket 4 in extension	Reuse

TORQUE SPECIFICATIONS - WINDSHIELD (REUSE HUMIDITY AND TEMPERATURE SENSOR) (HW3) - (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolt that attaches the GPS antenna to the bracket	1 N.m (.7 ft-lbs)	Torx T10 bit With a TorqueVario-S 0.8 N.m - 2.0 N.m screwdriver (installation only)	Reuse
Screws that attach the triple camera to the windshield bracket	1 N.m (.7 ft-lbs)	Torx T10 blade attachment Wiha TorqueVario-S 0.8 N.m - 2.0 N.m screwdriver (installation only) Wiha torque setter

TORQUE SPECIFICATIONS - FASCIA, REAR, LOWER (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts that attach the lower rear fascia to the upper rear fascia	3 N.m (2.2 ft-lbs)	10 mm socket 4 in extension	Reuse

TORQUE SPECIFICATIONS - FASCIA, REAR, UPPER (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts (x6) that attach the lower rear fascia to the upper rear fascia	3 N.m (2.2 ft-lbs)	10 mm socket 4 in extension	Reuse

TORQUE SPECIFICATIONS - GRILLE, FASCIA, FRONT (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Screws that attach the front fascia grille to the front fascia	3 N.m (2.2 ft-lbs)	Torx T25 socket 4 in extension	Reuse

TORQUE SPECIFICATIONS - BRACKET, REAR, CENTER (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts that attach the rear center bracket to the body	4 N.m (2.9 ft-lbs)	10 mm socket 4 in extension	Reuse

TORQUE SPECIFICATIONS - BUMPER BEAM, REAR (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Nuts that attach the rear bumper beam to the body	62.5 N.m (46.1 ft-lbs)	15 mm deep socket 6 in extension	Reuse

TORQUE SPECIFICATIONS - BUMPER BEAM, FRONT (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts that attach the front bumper beam to the crush cans	75 N.m (55.3 ft-lbs)	15 mm socket 3 in extension	Replace

TORQUE SPECIFICATIONS - LIFTGATE (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace
Bolts that attach the liftgate ball stud bracket to the liftgate	11 N.m (8.1 ft-lbs)	Torx T25 socket Flex head ratchet/flex head torque wrench 4 in extension	Reuse
Bolt that attaches the liftgate harness ground strap to the liftgate	8 N.m (5.9 ft-lbs)	10 mm deep socket Flex head ratchet/flex head torque wrench	NOTE: Inspect the bolt: if it is a standard bolt (1447438-00-A), it can be reused. If it is a self-tapping tri-lobular bolt (1128269-00-A), discard and replace with the standard bolt.
Bolts that attach the liftgate to the vehicle	32 N.m (23.6 ft-lbs)	13 mm socket Flex head ratchet/flex head torque wrench	Reuse
Screw that attaches the antenna filter electrical connector to the liftgate	2 N.m (1.5 ft-lbs)	Torx T30 socket Flex head ratchet/flex head torque wrench	Reuse
Bolt that attaches the RH FM amplifier to the liftgate	4 N.m (2.9 ft-lbs)	10 mm deep socket Flex head ratchet/flex head torque wrench	Reuse
Bolts that attach the radio tuner to the liftgate	8 N.m (5.9 ft-lbs)	10 mm deep socket Flex head ratchet/flex head torque wrench	Reuse
Screws that attach the license plate bracket to the liftgate	1.2 N.m (.9 ft-lbs)	PH2 Phillips screwdriver	Reuse

TORQUE SPECIFICATIONS - PANEL ASSEMBLY, REAR (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts that attach the rear end panel to the body	10 N.m (7.4 ft-lbs)	10 mm socket 4 in extension	Reuse
Bolt that attaches the Bluetooth passive entry module to the rear fascia center bracket	3.5 N.m (2.6 ft-lbs)	10 mm socket 4 in extension	Reuse

TORQUE SPECIFICATIONS - VALANCE, FRONT FASCIA (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Nut that attaches the RH corner of the front valance to the front fascia	3 N.m (2.2 ft-lbs)	10 mm deep socket Flex head ratchet/flex head torque wrench	Reuse

TORQUE SPECIFICATIONS - UPPER LEG SUPPORT - BUMPER CARRIER - FRONT (REMOVE AND REPLACE)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts (x4) that attach the upper leg support to the front end carrier	8 N.m (5.9 lbs-ft)	10 mm deep socket 6 in extension Flex head ratchet/flex head torque wrench	Reuse
