Neutral/Start Switch Specifications: Notes

NEUTRAL/START SWITCH SPECIFICATIONS VAN

Gearshift Position Terminal Continuity
"P" B & N
"R" RB & RL
"N" B & N
Fig 1: Neutral/Start Switch Terminal ID - Van
G118904Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
