Cruise Control Main Switch ASSY: Replacement

PRECAUTION
DISCONNECT BATTERY NEGATIVE TERMINAL
PLACE FRONT WHEELS FACING STRAIGHT AHEAD
REMOVE HORN BUTTON ASSY (See AIR BAG SENSOR ASSEMBLY )
REMOVE STEERING WHEEL ASSY (See step 6 under OVERHAUL )
SST 09950-50013 (09951-05010, 09952-05010, 09953-05020, 09954-05021)
REMOVE STEERING WHEEL BOSS COVER LOWER
1. Remove the 2 screws and steering wheel damper.

  Fig 1: Removing Steering Wheel Damper
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Remove the 3 screws and steering boss cover lower.

  Fig 2: Removing Steering Boss Cover Lower
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
REMOVE CRUISE CONTROL MAIN SWITCH ASSY
1. Remove the 2 screws and cruise control main switch assy.

  Fig 3: Removing Cruise Control Main Switch Assembly
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
ADJUST SPIRAL CABLE SUB-ASSY
INSTALL STEERING WHEEL ASSY (See step 47 under OVERHAUL )
STEERING WHEEL CENTER POINT
INSPECT HORN BUTTON ASSY (See AIR BAG SENSOR ASSEMBLY )
INSTALL HORN BUTTON ASSY (See AIR BAG SENSOR ASSEMBLY )
INSPECT SRS WARNING LIGHT (See AIR BAG WARNING LIGHT CHECK )
