Service Data





SPECIFICATIONS: MF1A TRANSFER / 4WD / AWD: SERVICE DATA






Thrust Washer Thickness (Backlash Adjust)










Thrust Washer Thickness (Tooth Adjust)






Thrust Washer Thickness (Preload Adjust)
