Toe-In ADJUSTMEN: Rear

Loosen nut "a" on control arm. See Fig 1 .

NOTE: If toe-in setting at rear wheels needs adjusting, also check brake pressure regulator setting. Adjust as needed. See appropriate BRAKE SYSTEMS article for specifications.

Move control arm forward or back until specification is achieved (vehicle weight on its wheels.) Tighten nut "a" to specification. See TORQUE SPECIFICATIONS . After fasteners are torqued, recheck all wheel alignment settings and readjust as necessary.

Fig 1: Adjusting Toe (Rear Axle)

Courtesy of VOLKSWAGEN UNITED STATES, INC.
