Solenoid Test

Connect battery negative lead to starter solenoid terminal "M". Connect battery positive lead to solenoid terminal No. 50. See Figure. If plunger does not extend firmly, replace solenoid.

Fig 1: Testing Starter Solenoid

Courtesy of VOLVO CARS OF NORTH AMERICA.
