Installing control module

Fig 1: Identifying Engine Control Module

Courtesy of VOLVO CARS OF NORTH AMERICA.

Carefully press the control module down into the grooves inside the control module box. Press home!

Bring down tool 9995722 around the control module.

Move the upper section of the tool forwards to stop and pull up the tool.

Press the cover over the control modules.

Check that the air ducts are correctly positioned.

Reinstall the cable to the battery negative terminal. First read Battery, disconnecting .
