Installing the Spring Strut/Wheel Spindle

Fig 1: Tightening Lock Nuts

Courtesy of VOLVO CARS OF NORTH AMERICA.

Install the spring strut on the wheel spindle. Use new screws and nuts  .

Adjust in accordance with the measured values.

Tighten to 105 Nm  . Angle-tighten 90°  . Use bevel protractor 9512050 .
